Summary

Stauff SP-035-E-10-B/4 Replaces the Stauff SP035E10B

Stauff SP035E10B
Stauff SP035E10B
Representative product image Product image feedback

Stauff SP-035-E-10-B/4 Pressure Filter | Replaces the Stauff SP035E10B

Brand: Stauff
Description

Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 49,5 Inner Diameter (mm): 23,9 Length (mm): 328,5 Sealing: NBR, β ratio >200

Price Match
$143.00
468 pcs
Germany
8421.99.90
2.87 lbs
0.029 ft³
468 pcs
United Kingdom
8421.99.90
0.86 lbs
0.05 ft³
468 pcs
United States
8421.29.80.90
1.3 lbs
0.029 ft³
468 pcs
Italy
8421.99.90
1.1 lbs
0.051 ft³
468 pcs
France
8421.99.90
Shipping Terms

Description

Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 49,5 Inner Diameter (mm): 23,9 Length (mm): 328,5 Sealing: NBR, β ratio >200

Specification

StylePressure Filter
MediaGlass Fiber
Efficiency 110µ @ β200
Efficiency 212µ @ β1000
Outer Diameter 1 15/16"
Inner Diameter 15/16"
Length 12 15/16"
Δ Collapse Pressure 304.6 psi
Seal MaterialNitrile
Temperature Range -20 - +210°F
Stauff Brand Logo

Stauff Product

Genuine Stauff SP-035-E-10-B/4

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
10µ @ β200
Efficiency 2 12µ @ β1000
Style Pressure Filter
Outer Diameter 1.97 in
Inner Diameter 0.96 in
Length 12.95 in
Media Type Glass Fiber
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 305 PSI
Seal Nitrile
Temperature Range -20 - +210°F
