Summary

Stauff SL-045-D-20-B Replacement Pressure Filter

Stauff SL-045-D-20-B
Stauff SL-045-D-20-B
Representative product image Product image feedback

Stauff SL-045-D-20-B Pressure Filter

Brand: Stauff
Description

Replacement Filter Element for Pressure Filters Micron Rating: 20 µm Material: Filter Paper Outer Diameter (mm): 82,5 Inner Diameter (mm): 47,5 Length (mm): 142 Sealing: NBR, β ratio >2

Price Match
$100.00
66 pcs
Germany
8421.99.90
0.97 lbs
0.059 ft³
66 pcs
France
8421.99.90
66 pcs
Germany
8421.99.90
1.01 lbs
0.035 ft³
66 pcs
Italy
8421.99.90
1.08 lbs
0.073 ft³
66 pcs
United States
8421.29.80.90
1.05 lbs
0.048 ft³
66 pcs
Italy
8421.23.00
Shipping Terms

Description

Replacement Filter Element for Pressure Filters Micron Rating: 20 µm Material: Filter Paper Outer Diameter (mm): 82,5 Inner Diameter (mm): 47,5 Length (mm): 142 Sealing: NBR, β ratio >2

Specification

StylePressure Filter
MediaCellulose
Efficiency 125µ @ β2
Outer Diameter 3 1/4"
Inner Diameter 1 7/8"
Length 5 9/16"
Δ Collapse Pressure 435.1 psi
Seal MaterialViton
Temperature Range -10 - +250°F
Stauff Brand Logo

Stauff Product

Genuine Stauff SL-045-D-20-B

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
25µ @ β2
Efficiency 2
Style Pressure Filter
Outer Diameter 3.27 in
Inner Diameter 1.87 in
Length 5.59 in
Media Type Cellulose
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 435 PSI
Seal Viton
Temperature Range -10 - +250°F
