Stauff SGB-090-03-B Replacement Spin-On Filter

Stauff SGB-090-03-B
Stauff SGB-090-03-B
Representative product image Product image feedback

Stauff SGB-090-03-B Spin-On Filter

Brand: Stauff
Description

Particle Breather (Air Breather Element) Diameter 100 mm Spin-On Design G3/4 BSP Female Inorganic Glass Fibre Micron Rating 3 μm

Price Match
$51.00
Germany
8421.99.90
0.64 lbs
0.019 ft³
Italy
8421.99.90
1.06 lbs
0.025 ft³
Italy
8421.23.00
Shipping Terms

Description

Particle Breather (Air Breather Element) Diameter 100 mm Spin-On Design G3/4 BSP Female Inorganic Glass Fibre Micron Rating 3 μm

Specification

StyleSpin-On Filter
MediaGlass Fiber
Efficiency 13µ @ β200
Efficiency 25µ @ β1000
Outer Diameter 3 3/4"
Length 2 3/8"
Thread3/4" BSP
Δ Collapse Pressure 174.0 psi
Seal MaterialNitrile
Temperature Range -20 - +210°F
Stauff Brand Logo

Stauff Product

Genuine Stauff SGB-090-03-B

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
3µ @ β200
Efficiency 2 5µ @ β1000
Style Spin-On Filter
Outer Diameter 3.78 in
Inner Diameter
Length 2.36 in
Media Type Glass Fiber
Flow Direction
Thread 3/4" BSP
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 174 PSI
Seal Nitrile
Temperature Range -20 - +210°F
