Summary

Stauff SF-6505 Replaces the Stauff SF6505

Stauff SF6505
Representative product image Product image feedback

Stauff SF-6505 Replaces the Stauff SF6505

SF-6505
Stauff
Stauff SF6505
Description

Replacement Filter Element Spin-On Filter Cartridge Micron Rating: 12 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 93,2 Length (mm): 147 Sealing: NBR, β ratio >200

Brand: Stauff
Price Matched
$49.00
1.38 lbs
8421.99.90
Germany
1.5 lbs
8421.99.90
France
1.46 lbs
8421.99.90
Italy
Shipping Terms

Description

Replacement Filter Element Spin-On Filter Cartridge Micron Rating: 12 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 93,2 Length (mm): 147 Sealing: NBR, β ratio >200

Specification

StyleSpin-On Filter
Efficiency 110µ @ β200
Efficiency 212µ @ β1000
Outer Diameter 3.78 in
Length 5.79 in
Thread1"-12 UNF
MediaGlass Fiber
Δ Collapse Pressure 174 PSI
Seal MaterialNitrile
Temperature Range -20 - +210°F

Genuine Product

Find out more
Stauff Brand Logo

Stauff Product

Genuine Stauff SF-6505

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
10µ @ β200
Efficiency 2 12µ @ β1000
Style Spin-On Filter
Outer Diameter 3.78 in
Inner Diameter
Length 5.79 in
Media Type Glass Fiber
Flow Direction
Thread 1"-12 UNF
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 174 PSI
Seal Nitrile
Temperature Range -20 - +210°F
