Stauff SF-6728-MG Replacement Spin-On Filter

Stauff SF-6728-MG
Stauff SF-6728-MG
Representative product image Product image feedback

Stauff SF-6728-MG Spin-On Filter

Brand: Stauff
Description

Replacement Filter Element Spin-On Filter Cartridge Micron Rating: 25 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 128 Sealing: NBR, β ratio >200

Price Match
$146.00
320 pcs
Germany
8421.99.90
2.16 lbs
0.109 ft³
320 pcs
France
8421.99.90
2.69 lbs
0.133 ft³
320 pcs
United States
8421.29.80.90
2.82 lbs
0.099 ft³
320 pcs
Italy
8421.99.90
2.69 lbs
0.129 ft³
320 pcs
Mexico
8421.23.00
320 pcs
Germany
8421.99.90
Shipping Terms

Description

Replacement Filter Element Spin-On Filter Cartridge Micron Rating: 25 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 128 Sealing: NBR, β ratio >200

Specification

StyleSpin-On Filter
MediaGlass Fiber
Efficiency 120µ @ β200
Efficiency 222µ @ β1000
Outer Diameter 5 1/16"
Length 6 11/16"
Thread1 1/2"-16 UN
Δ Collapse Pressure 203.1 psi
Seal MaterialNitrile
Temperature Range -20 - +210°F
Stauff Brand Logo

Stauff Product

Genuine Stauff SF-6728-MG

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
20µ @ β200
Efficiency 2 22µ @ β1000
Style Spin-On Filter
Outer Diameter 5.04 in
Inner Diameter
Length 6.69 in
Media Type Glass Fiber
Flow Direction
Thread 1 1/2"-16 UN
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 203 PSI
Seal Nitrile
Temperature Range -20 - +210°F
