Summary

Stauff RTE-25-D-10-B Replaces the Stauff RTM0272N10B

Stauff RTM0272N10B
Stauff RTM0272N10B
Representative product image Product image feedback

Stauff RTE-25-D-10-B Return Filter | Replaces the Stauff RTM0272N10B

Brand: Stauff
Description

Return Line Filter Element Filter Paper 10µm

Price Match
$32.00
700 pcs
Germany
8421.99.90
0.49 lbs
0.043 ft³
700 pcs
France
8421.99.90
0.62 lbs
0.043 ft³
700 pcs
Italy
8421.29.80.90
0.57 lbs
0.023 ft³
700 pcs
Italy
8421.99.90
Shipping Terms

Description

Return Line Filter Element Filter Paper 10µm

Specification

StyleReturn Filter
MediaCellulose
Efficiency 110µ @ β2
Outer Diameter 2 3/4"
Inner Diameter 1 3/16"
Length 5"
Bypass Pressure 15 psi
Δ Collapse Pressure 145.0 psi
Seal MaterialNitrile
Temperature Range -20 - +210°F
Stauff Brand Logo

Stauff Product

Genuine Stauff RTE-25-D-10-B

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
10µ @ β2
Efficiency 2
Style Return Filter
Outer Diameter 2.76 in
Inner Diameter 1.16 in
Length 5.0 in
Media Type Cellulose
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

15 PSI
Collapse Pressure 145 PSI
Seal Nitrile
Temperature Range -20 - +210°F
