Stauff RE-090-G-05-B/4 Replaces the Stauff RE090G05B4
Stauff RE-090-G-05-B/4 Replaces the Stauff RE090G05B4
RE-090-G-05-B/4
Stauff
Stauff RE090G05B4
Stauff
Stauff RE090G05B4
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 5 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 95 Inner Diameter (mm): 48,5 Length (mm): 195 Sealing: NBR, β ratio >200
Brand:
Stauff
Regular price
$149.00
Unit price
per
1.85 lbs
8421.99.90
Germany
1.81 lbs
8421.99.90
Italy
1.81 lbs
8421.99.90
France
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 5 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 95 Inner Diameter (mm): 48,5 Length (mm): 195 Sealing: NBR, β ratio >200Specification
| Style | Return Filter |
| Efficiency 1 | 5µ @ β200 |
| Efficiency 2 | 7µ @ β1000 |
| Outer Diameter | 3.72 in |
| Inner Diameter | 1.9 in |
| Length | 7.64 in |
| Bypass Pressure | 44 PSI |
| Media | Glass Fiber |
| Flow Direction | OUT-IN |
| Δ Collapse Pressure | 290 PSI |
| Seal Material | Nitrile |
| Temperature Range | -20 - +210°F |
