Stauff RE-300-G-10-B/5 Replacement Return Filter
Stauff RE-300-G-10-B/5 Replacement Return Filter
RE-300-G-10-B/5
Stauff
Stauff
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 143 Inner Diameter (mm): 96,1 Length (mm): 483 Sealing: NBR, β ratio >200
Brand:
Stauff
Regular price
$416.00
Unit price
per
8.85 lbs
8421.99.90
Germany
6.61 lbs
8421.99.90
France
6.48 lbs
8421.29.80.90
United States
10.61 lbs
8421.99.90
Italy
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 143 Inner Diameter (mm): 96,1 Length (mm): 483 Sealing: NBR, β ratio >200Specification
| Style | Return Filter |
| Efficiency 1 | 10µ @ β200 |
| Efficiency 2 | 12µ @ β1000 |
| Outer Diameter | 5.65 in |
| Inner Diameter | 3.8 in |
| Length | 19.02 in |
| Bypass Pressure | 44 PSI |
| Media | Glass Fiber |
| Flow Direction | OUT-IN |
| Δ Collapse Pressure | 290 PSI |
| Seal Material | Nitrile |
| Temperature Range | -20 - +210°F |
