Stauff RE-070-G-10-B/4 Replaces the Stauff R240G10B4
Stauff RE-070-G-10-B/4 Replaces the Stauff R240G10B4
RE-070-G-10-B/4
Stauff
Stauff R240G10B4
Stauff
Stauff R240G10B4
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 74 Inner Diameter (mm): 34,2 Length (mm): 203 Sealing: NBR, β ratio >200
Brand:
Stauff
Regular price
$125.00
Unit price
per
1.03 lbs
8421.99.90
Germany
1.17 lbs
8421.99.90
Italy
0.93 lbs
8421.99.90
France
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 74 Inner Diameter (mm): 34,2 Length (mm): 203 Sealing: NBR, β ratio >200Specification
| Style | Return Filter |
| Efficiency 1 | 10µ @ β200 |
| Efficiency 2 | 12µ @ β1000 |
| Outer Diameter | 2.89 in |
| Inner Diameter | 1.35 in |
| Length | 7.99 in |
| Bypass Pressure | 44 PSI |
| Media | Glass Fiber |
| Flow Direction | OUT-IN |
| Δ Collapse Pressure | 290 PSI |
| Seal Material | Nitrile |
| Temperature Range | -20 - +210°F |
