Stauff NL-063-E-25-B/4 Replaces the Stauff NL063E25B
Stauff NL-063-E-25-B/4 Replaces the Stauff NL063E25B
NL-063-E-25-B/4
Stauff
Stauff NL063E25B
Stauff
Stauff NL063E25B
Description
Replacement Filter Element for Medium-Pressure Filters Micron Rating: 25 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 44,5 Inner Diameter (mm): 22,2 Length (mm): 159 Sealing: NBR, β ratio >200
Brand:
Stauff
Regular price
$96.00
Unit price
per
0.5 lbs
8421.99.90
Germany
0.57 lbs
8421.99.90
France
0.66 lbs
8421.99.90
Italy
Description
Replacement Filter Element for Medium-Pressure Filters Micron Rating: 25 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 44,5 Inner Diameter (mm): 22,2 Length (mm): 159 Sealing: NBR, β ratio >200Specification
| Style | DIN Pressure Filter |
| Efficiency 1 | 20µ @ β200 |
| Efficiency 2 | 22µ @ β1000 |
| Outer Diameter | 1.75 in |
| Inner Diameter | 0.87 in |
| Length | 6.18 in |
| Media | Glass Fiber |
| Flow Direction | OUT-IN |
| Δ Collapse Pressure | 305 PSI |
| Seal Material | Nitrile |
| Temperature Range | -20 - +210°F |
Genuine Product
Find out more
Stauff Product
Genuine Stauff NL-063-E-25-B/4
Inspected to ISO 9001:2015
See Our Certification
Free 45-Day Returns
Return Policy
