Stauff SF-6710 Replaces the Stauff FI-GE-18LR3/4-WD-B-W3-MS

FI-GE-18LR3/4-WD-B-W3-MS
FI-GE-18LR3/4-WD-B-W3-MS
Representative product image Product image feedback

Stauff SF-6710 Spin-On Filter | Replaces the Stauff FI-GE-18LR3/4-WD-B-W3-MS

Brand: Stauff
Description

Replacement Filter Element Spin-On Filter Cartridge Micron Rating: 25 µm Material: Filter Paper Outer Diameter (mm): 128 Length (mm): 168 Sealing: NBR, β ratio >2

Price Match
$43.00
360 pcs
Germany
8421.99.90
2.58 lbs
0.113 ft³
6 pcs
360 pcs
United States
8421.29.80.90
2.36 lbs
0.113 ft³
360 pcs
France
8421.99.90
2.65 lbs
0.099 ft³
360 pcs
Italy
8421.99.90
Shipping Terms

Description

Replacement Filter Element Spin-On Filter Cartridge Micron Rating: 25 µm Material: Filter Paper Outer Diameter (mm): 128 Length (mm): 168 Sealing: NBR, β ratio >2

Specification

StyleSpin-On Filter
MediaCellulose
Efficiency 125µ @ β2
Outer Diameter 5 1/16"
Length 6 11/16"
Thread1 1/2"-16 UN
Δ Collapse Pressure 203.1 psi
Seal MaterialNitrile
Temperature Range -20 - +210°F
Stauff Brand Logo

Stauff Product

Genuine Stauff SF-6710

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
25µ @ β2
Efficiency 2
Style Spin-On Filter
Outer Diameter 5.04 in
Inner Diameter
Length 6.69 in
Media Type Cellulose
Flow Direction
Thread 1 1/2"-16 UN
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 203 PSI
Seal Nitrile
Temperature Range -20 - +210°F
