Specification

Efficiency 160µ
Outer Diameter 1.81 in
Inner Diameter 0.81 in
Length 3.11 in
Bypass Pressure 15 PSI
MediaWire Mesh
Flow DirectionOUT-IN
Δ Collapse Pressure 116 PSI
SealNitrile
Temperature Range -20 - +210°F

What is FilterFinder Approved?

Our FilterFinder Approval guarantees that our replacement filters will meet or exceed the quality and performance standards set by OEMs. We are committed to quality assurance, performance, and compatibility ensuring you get a consistently reliable product every time.

Our elements offer a cost-effective solution, without sacrificing on quality or performance, providing you with reliable and high-quality replacement product.

Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
60µ
Efficiency 2
Style Return Filter
Outer Diameter 1.81 in
Inner Diameter 0.81 in
Length 3.11 in
Media Type Wire Mesh
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

15 PSI
Collapse Pressure 116 PSI
Seal Nitrile
Temperature Range -20 - +210°F
