Specification

Efficiency 110µ @ β2
Outer Diameter 5.12 in
Inner Diameter 2.54 in
Length 5.71 in
Bypass Pressure 15 PSI
MediaCellulose
Flow DirectionOUT-IN
Δ Collapse Pressure 145 PSI
SealNitrile
Temperature Range -20 - +210°F

Why Choose FilterFinder

We pride ourselves on delivering exceptional value and service to our customers. With over £8M of stock available in under 3 weeks, you can be confident that we'll have what you need exactly when you need it, helping to keep your operations running smoothly.

Our filters are not only affordable but also of great value, providing reliable performance and long-lasting durability.

Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
10µ @ β2
Efficiency 2
Style Return Filter
Outer Diameter 5.12 in
Inner Diameter 2.54 in
Length 5.71 in
Media Type Cellulose
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

15 PSI
Collapse Pressure 145 PSI
Seal Nitrile
Temperature Range -20 - +210°F
