MicroFit MFHR50816 Replaces the UFI Filter ERF34NFB

MICROFIT MFHR50816
MICROFIT MFHR50816
Representative product image Product image feedback

MicroFit® UltraGen III MFHR50816 Return Filter | Replaces the UFI Filter ERF34NFB

Brand: MicroFit
Description

The MICROFIT® UltraGen III MFHR50816 is the MICROFIT® approved replacement to the UFI ERF34NFB. Engineered and manufactured in Great Britain the MFHR50816

Price Match
$99.00
8.75 lbs
0.269 ft³
80 pcs
United Kingdom
8421.99.90
5.62 lbs
0.397 ft³
80 pcs
Italy
8421.29.80.90
4.06 lbs
0.375 ft³
80 pcs
France
8421.99.90
3.97 lbs
0.269 ft³
80 pcs
Italy
8421.99.90
4.27 lbs
0.339 ft³
80 pcs
United States
8421.29.80
Shipping Terms

Description

The MICROFIT® UltraGen III MFHR50816 is the MICROFIT® approved replacement to the UFI ERF34NFB. Engineered and manufactured in Great Britain the MFHR50816

Specification

StyleReturn Filter
MediaGlass Fiber
Efficiency 15µ @ β200
Efficiency 27µ @ β1000
Outer Diameter 4 15/16"
Inner Diameter 3 5/8"
Length 18 7/8"
Seal MaterialNitrile
Temperature Range -20 - +210°F
Default Brand Logo

Same Fit-Form & Function

As the Genuine UFI Filter ERF34NFB

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
5µ @ β200
Efficiency 2 7µ @ β1000
Style Return Filter
Outer Diameter 4.96 in
Inner Diameter 3.62 in
Length 18.9 in
Media Type Glass Fiber
Flow Direction IN-OUT
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure
Seal Nitrile
Temperature Range -20 - +210°F
